Style 2172

Plaited

Plaited from synthetic yarn, thoroughly impregnated with PTFE suspensoid and a high grad break in lubricant.

This construction creates an exceptionally durable rotating pump packing. The PTFE suspensoid provides
low friction and minimal shaft wear, and the oil lubricant contributes to the life of the packing.
Construction
Plaited

Base Material
Synthetic yarn

Shape
Square

Lubricant
PTFE suspensoid and high grade mineral oil

Temperature
550oF/288oC

pH
3-11

 FPM
Shaft Speed 1600 Ft/Min.

Applications
Centrifugal and rotary pumps Air, water, sea water, brines, superheated steam, sludges, slurries, waste, petroleum oils, petroleum fuels, solvents, chemicals.

Advantages
Exceptionally durable. Minimized replacement frequency. High grade mineral oil provides initial break in lubrication. Counteracts start up friction.

Maximum Size
2"
Feet Per Pound
1/8" 3/16" 1/4" 5/16" 3/8" 7/16" 1/2" 9/16" 5/8" 11/16" 3/4" 7/8" 1"
107.99 48.54 27.17 17.39 12.94 9.08 7.08 5.57 4.50 3.90 3.35 2.46 1.81
